Productdetails:

Plaats van herkomst: Hunan, China
Merknaam: TENCAN
Certificering: ISO CE
Modelnummer: XQM-12

Betalen & Verzenden Algemene voorwaarden:

Min. bestelaantal: 1 set
Prijs: Onderhandelbaar
Verpakking Details: doos+schuim
Levertijd: 3-7 werkdagen na volledige betaling
Betalingscondities: T/T, Western Union
Levering vermogen: 300 sets per maand
Beste prijs Contact

Gedetailleerde informatie

Poructnaam: Vierkante vorm verticale laboratoriumbalfabriek Modelnr.: XQM-12
Totaal volume: 12L Maximale capaciteit: 3.96L
Roteer de snelheid: 70-580 tpm Snelheidsregeling: Frequentiecontrole
Spanning: 220V-50Hz of 110V-60Hz Stroom: 1,5 kW
Markeren:

12L programmable laboratory ball mill

,

planetary ball mill with real-time monitoring

,

versatile processing modes ball mill

Productomschrijving

12L Planetary Ball Mill with Programmable Cycles and Real-Time Monitoring for Smart Control and Versatile Processing Modes


Product Overview
Our advanced planetary ball mill represents a breakthrough in laboratory-scale material processing technology, delivering outstanding performance in nanomaterial grinding, powder homogenization, and sample preparation. Engineered to support pioneering research and small-scale manufacturing, this system integrates high-efficiency milling capabilities with intelligent control features, establishing itself as an essential tool for contemporary scientific laboratories.

Technical Innovation
The equipment employs an innovative multi-axis motion mechanism where grinding containers execute simultaneous planetary rotation and high-speed revolution. This sophisticated movement pattern generates intense centrifugal forces that achieve ultrafine particle processing down to 0.1μm. The optimized transmission system guarantees reproducible results while operating at substantially reduced acoustic levels compared to traditional milling equipment.



Key Benefits

  • Large 12L processing capacity with 4-station parallel operation for improved productivity

  • Intelligent control system supporting programmable parameters and live operation tracking

  • Multi-mode processing compatibility including vacuum, inert atmosphere, and low-temperature grinding

  • Comprehensive safety protection with dual-layer safety mechanisms and instant emergency shutdown

Application Areas

  • New Energy Materials: Anode/cathode powders, solid electrolytes, hydrogen energy materials

  • Electronic Components: Electronic ceramics, semiconductor substrates, conductive additives

  • Biomedical Materials: Pharmaceutical intermediates, tissue engineering scaffolds, bioactive coatings

  • Advanced Materials: Special alloys, nanocomposites, additive manufacturing powders

Technical Strengths

  • Exclusive vibration control technology ensuring exceptional operational stability

  • Modular architecture enabling rapid switching between wet and dry processing

  • Smart connectivity for remote equipment management and process optimization

  • High-efficiency power system cutting energy usage by over 30%

This advanced milling system achieves optimal integration of precision, capacity, and operational convenience, providing researchers with groundbreaking capabilities for materials development.

Competitive Advantages

  • Industry-leading fineness control for particle size reduction

  • Adaptable configuration supporting diverse research requirements

  • Durable construction with minimal maintenance demands

  • Complete technical support and customized solution services

Perfectly suited for national research institutes, academic laboratories, and innovative enterprises engaged in next-generation material development.





Technical Features



Technical Features
Drive Mode Gear drive and belt drive
Operate Mode Two or four grinding tanks working together
Maximum Loading Capacity 2/3 of the capacity of milling tank
Feeding Size Soil material≤3mm
Output Granularity Minimum 0.1μm
Rotational Speed Ratio /1/2
Max.Continuous Operating Time 72hours
Materials of Jar stainless steel.agate,nylon,corundum,zirconia,etc



Technical Parameters



Main Parameters of Vertical Planetary Mill Ball (SquareType)
Model Power(KW) Voltage Dimension(mm) Revolution Speed
(rpm)
RotationSpeed
(rpm)
XQM-1 0.75 220V-50Hz 750*470*564 35-325 70-670
XQM-2 0.75 220V-50Hz 750*470*564 35-335 70-670
XQM-4 0.75 220V-50Hz 750*470*564 35-335 70-670
XQM-6 0.75 220V-50Hz 750*470*564 35-335 70-670
XQM-8 1.5 220V-50Hz 900*600*640 35-290 70-580
XQM-10 1.5 220V-50Hz 900*600*640 35-290 70-580
XQM-12 1.5 220V-50Hz 900*600*640 35-290 70-580





Accessories of Grinding Pots & Balls



Available grinding pots in full sizes:

Stainless steel mill pot, zirconia mill pot, alumina mill pot, nylon mill pot, PU mill pot, tungsten mill pot, hard metal mill pot and tempered nylon mill pot etc.



12L Planetary Ball Mill with Programmable Cycles and Real-Time Monitoring for Smart Control and Versatile Processing Modes 0

References for Matchable Jar Sizes with Square Shape Planetary Ball Mill
Model No. Total Volume
(L)
Matchable Jar
Sizes
Matchable Jars
Quantity
Matchable Vacuum
Jar Sizes
XQM-2 2.0L 50-500ml 2pcs or 4pcs 50-250ml
XQM-4 4.0L 250-1000ml 2pcs or 4pcs 50-1000ml
XQM-6 6.0L 1-1.5L 2pcs or 4pcs 50-1000ml
XQM-8 8.0L 1-2L 2pcs or 4pcs 50-1500ml
XQM-10 10L 1-2.5L 2pcs or 4pcs 1-2L
XQM-12 12L 1-3L 2pcs or 4pcs 1-2L
XQM-20 20L 2-5L 2pcs or 4pcs 2-4L
XQM-40 40L 5-10L 2pcs or 4pcs 5L
XQM-60 60L 10-15L 2pcs or 4pcs 10L
XQM-100 100L 20-25L 2pcs or 4pcs 20L



Recommendation For Matching Solutions About Mill Jars & Materials
Categories of Materials Recommended Mill Jars
Soil and other Materials which are not allowed with any impurity Agate mill jar
Metal & nonmetal materials which are not allowed with any impurity Zirconia mill jar
High hardness materials like diamond, tungsten carbide Tungsten carbide mill jar
Strong add & alkali materials or other materials at high temperature PTFE mill jar
Iron ore materials with lower impurity sensitivity 304 Stainless steel mill jar
Pigment or other materials with later process under high temperature Nylon mill jar
Aluminum materials like ceramic glaze Corundum mill jar
Electronic materials like lithium battery Polyurethane mill jar
Easily oxidized materials or some special materials which need to
be protected under special atmosphere.
Vacuum mill jar



Available grinding balls in full sizes

Stainless steel balls, zirconia balls, alumina balls, PU balls, steel carbon balls, tungsten balls, agate balls, hard metal balls, silicon nitride balls, high wear resistant steel ball, manganese steel balls, cemented carbide, crystal glass and other special metal materials.

12L Planetary Ball Mill with Programmable Cycles and Real-Time Monitoring for Smart Control and Versatile Processing Modes 1



References About Grinding Medias & Materials
Materials of
Grinding Media
Hardness
(Mohs)
Features
Zirconia Balls ≥9.0 Super wear-resistance, without any impurity, corrosion & high temperature resistance.
Stainless Steel Balls ≥6.0 Wear-resistant, general corrsion resistance, high temperature resistance.
Agate Balls ≥7.0 Super wear-resistance, used for medicine,food and other materials which can not be contaminated with metal, corrosion, and high temperature resistance.
Alumina Balls ≥8.5 Wear-resistant, corrsion resistance and high temperature resistance.
Tungsten Carbide Balls ≥9.0 Super wear-resistance, without any impurity, corrosion & high temperature resistance.



Matching Solutions for Mill Jars & Balls
Items Agate Balls Alumina Balls Stainless Steel Balls Zirconia Balls Tungsten Carbide Balls
Agate Mill jar
Corundum Mill Jar
Stainless Steel Mill Jar
Zirconia Mill Jar
Nylon Mill Jar
PTFE Mill Jar
Polyurethane Mill Jar
Tungsten Carbide Mill Jar
√ means: most suitable ▲ means: suitable
